2ton one piece frame wheel loader for good quality

Basic Info.

Model NO.	TL20
Type	Small Loader
Max. Tractive Force	55kn
Max. Dumping Height	4400mm
Running Speed	36.8kph
Max. Breakout Force	>58kn
Engine	Changchai
Rated Power	72kw
Bucket Capacity	1.1cbm
Operating Weight	5800kg
Transport Package	Nude in Container
Specification	6300*2000*2900
Trademark	TITAN
Origin	China
HS Code	84295100
Production Capacity	1000/Year

Product Description

2ton one piece frame wheel loader for good quality

1. High reliability and productivity. Adopt weichai Deutz or YUCHAI engine, powerful and reliable.Torque converter and counter-shaft transmission gearbox, assembled separately, higher reliability and easier maintenance.2. Fully hydraulic steering system, powedr shift transmission, easier operation.Bucket can be leveled automatically, optimized working device,higher productivity.3. Comfortable operation environment, new desigh cabin, air-condition at option.4. Various working devices of attachment are available, such as log grapple, pipe fork, grass fork, stone bucket,snowblade, pallet fork etc. to meet different need.1) 2000kg capacity, 1.1cbm, 5800kg operating weight.2) Maximum speed 36km/h,fast3) Dumping height:4400mm.4) Luxury appearance5) With many attachments,all configuratin customer can choose6) Safe and comfortable cabs,comfortable seat allowing the operator to work in confidenceand to focus on a productive working day.7) Up to 10% lower fuel consumption.8) Highest payloads and tipping loads9) Low operating costs.10) East to operate.11) With substantial loading capacity,powerful digging force and impressive travel speeds,they are extremely productive.12) Fuel-efficient and easy to maintain,they offer reduced running costs.

TL20 WHEEL LOADER SPECIFICATION
Item	Feature
Overall working weight	5800kg
Rated bucket capacity	1.1m3
Rated load	2000kg
Max. tractive force	55KN
Max. breakout force	≥58KN
Max gradeablity	30o
Max. dumping height	4400mm
Dumping distance	900mm
Overall dimension	5900*2100*2900mm
Engine
Model	Changchai
Type	inline, water cooling, dry cylinder, direct injection
Number of cylinder-bore/stroke	4
Rated power	70kw
Rated speed	2200r/min
Mini fuel-consume ratio	220g/kw.h
Transmission system
Torque converter	Single-stage
Torque ratio	3.2
Transmission type	Planetary power shift
Gear shift	2 forwardshift, 2 reverseshift
Max. speed	24km/h
Front and rear axles
Main transmission type	Sprial gear, first stage decelerate
Final decelerate type	Fist stage, planetary gear decelerate
Tyre
Tyre specification	16/70-20
Front tyre pressure	350KPa
Rear tyre pressure	350KPa
Steering system
Steering System Type	Articulated load-sensing hydraulic steering system
Steering angle	±35o
Mini turning radius	4800mm
system working pressure	16MPa
Boom lifting time	5s
Total time	10s
Brake system
Sevice brake	Air-on-oil, caliper-disk
parking brake	Manual caliper disc
Capacity
Fuel	60L
Hydraulic	60L

The standard equipment:

---Standard Bucket or 4 in 1 bucket and pallet fork,---Hydraulic Torque Converter Transmission,---Floating Function,---Pilot joystick control,---130W Heater, 220V Engine Heater,---Rops&Fops Cabin,---Tipping Cabin,---Luxury Cabin Inside,---Backward Imagine,---Comfortable Seat,---Adjustable Steering Wheel,---Wheel Reducer Axle,---Air Brake,---Lock for Lifting and Steering Cylinder,---Hydraulic Pressure Check System,---Parallel Linkage,---Free Service Spare Parts etc.
